Adopting high-precision through type transformers, completely isolated from the primary circuit, with high safety;

Adopting a distributed measurement structure, namely on-site measurement and digital transmission;

Adopting digital filtering methods to eliminate the "zero drift problem" caused by analog filters;

Adopting nationally produced chips, independent and reliable;

Adopting differential pulse and self-developed synchronous control algorithm to achieve distributed high-precision synchronous measurement (1uS)

High measurement accuracy, all better than the national standard requirements;

LED display screens can be used on the device to display monitoring data for easy observation.

Performance: Meets the Technical Specification for Online Monitoring Devices for Substation Equipment Part 3: Capacitive Equipment and Metal Oxide Surge Arresters (DL/T 1498.3-2016)

Power supply: AC220V;

Display: None/LED

Monitoring parameters: full current, resistive current, resistance capacitance ratio, number of actions;

Communication: RS485; Communication protocol: MODBUS-RTU;

1. Technical indicators of device operation:

2. Technical indicators for device measurement:

3. Remote communication

4. Insulation performance

5. Electromagnetic compatibility performance

• 避雷器状态在线监测装置主要监测变电站(所) 35KV及以上电压等级的金属氧化物避雷器。

• 对运行中的避雷器绝缘状况进行连续的在线监测，随时获得能反映设备绝缘状况变化的信息，可提高设备检修工作的针对性和有效性，合理降低检修成本，做到有的放矢地维修，可更有效地使用设备，提高设备的使用率，使设备运行更安全、可靠。
