Adopting a core through type residual current sensor does not affect the circuit structure of the primary equipment and does not increase the residual voltage at the high-voltage end of the lightning arrester;

Strong anti-interference ability, especially the ability to resist interference from power frequency magnetic fields;

Real time monitoring and recording of leakage current and discharge action information of lightning arresters, allowing for historical queries on leakage current and discharge action time;

When the leakage current value exceeds the set threshold, the normally open contact will close and trigger an alarm. The threshold can be set according to requirements;

Communicate with backend monitoring devices through RS485 bus; Meet the technical specifications of QGDW12355_2023 Smart Substation Part 4: Digital Remote Transmission Meter, Communication Requirements (see Appendix 1)

Performance: Meets the Technical Specification for Smart Substations Part 4: Digital Remote Transmission Meter (Q/GDW 12355.4-2023);

供电：AC/DC110V (AC/DC220V)；

Display: 4.3 'TFT LCD;

Monitoring: full current, number of actions;

Communication: RS485;

Main technical parameters:

组网说明

RS485 通信应采用专用屏蔽双绞线电缆进行手拉手连接， 并且将屏蔽层单端连接地，一般采用终端匹配的总线型结构 ；RS485传输距离超过500m，在传输总线的两端需要 2个终接电阻，其阻值要求等于传输电缆的特性阻抗（一般为 120 Ω )。

附表1：

避雷器数字化泄漏电流表数据标识表
